External Cylindrical Laser Cladding Machine
This equipment is suitable for laser cladding processing of multi-variety, large-batch shaft workpieces with a weight ≤10t and length ≤20m; it features an open-structure design for quick loading and unloading of workpieces; it uses an intelligent operation control system that is simple, flexible, and convenient to operate; optional configurations include CCD molten pool monitoring, molten pool temperature closed-loop control, adaptive height following system, oscillation system, online preheating system, wire (cold wire/hot wire) components and systems, etc.
Performance Features
High Adaptability
Can meet the cladding/additive processing of shaft-type workpieces with weight ≤10t and length ≤20m
Efficient Nozzle
High-power needle-type powder feeding and annular powder feeding water-cooled nozzles meet the needs of high-power laser processing
Intelligent Control
Centralized control, powerful functions, easy operation; supports 2D/3D graphics import, no programming required
High Stability
Single unit capacity can reach 10 ㎡/day, capable of continuous stable production for 24 hours
Modular Design
Rich configuration, equipped with multi-brand lasers and cladding heads to meet the processing needs of different types of workpieces
Good molding quality
Advanced spot homogenization technology ensures the consistency of the melt pool, achieving a high-quality cladding layer with Ra≤6.3um.
Technical Parameters
| Structure: Casting/Welding | Laser: 3-12KW | Workpiece Diameter: ≤1600mm | Workpiece Length: ≤20000mm |
| Load: ≤10t | Rotational Speed: 0-100r/min | Cladding Thickness: ≤2.5mm (Single Layer) | Cladding Efficiency: 0.3-1.6m²/h |
| Function: Cladding/Quenching | Cladding Head: Coaxial Annular/Coaxial Broadband/Off-axis Broadband, etc. | Operating System: PLC/CNC/No Programming | Optional Functions: CCD/Molten Pool Closed-loop/Adaptive Height Following/Swing System/Online Preheating, etc. |
